Mastech My8301 Multimeter

7,800.00

New
Compare

Mastech My8301 Multimeter

Features

Display 6000 Counts
Auto range
Auto Power Off
Dual Display
Continuity Buzzer
Data Hold
MAX/MIN
Display Backlight
Low Battery Display
Non-Contact Voltage Detector

Specification
SpecificationsRangeResolutionAccuracy
DC Voltage6V/60V/600V0.01V/0.1V/1V(0.5%+3)
AC Voltage6V/60V/600V0.01V/0.1V/1V(0.8%+5)
Resistance
2kv/20kv/200kv/2Mv
0.001kv/0.01kv/0.1kv/0.001M??
(0.8%+3)
10Mv0.01Mv(1.0%+5)
Frequency60Hz/600Hz/3kHz0.1Hz/1Hz/10Hz(1.0%+5)
Duty Cycle10%«?90%1%2.0%

Power Supply : 2×1.5V AAA Batteries
Product Size : 150mm x 74mm x 48mm / 5.9”x2.9”x1.7”
Product Weight : 220g / 0.48lb
Certificate : CE / ETL / RoHS
Safety Rating : CAT III 600V

Check out more Test And Measurement Product:Fluke 922 Airflow Meter/Micro-manometer,  Fluke VT04A IR Visual Thermometer, fluke 323 clamp meter,  Mastech MS8217 auto range multi-meter,  UNI-T 205 Clamp Meter, UNI-T 302D Infrared  Thermometer, And many mor

Download User Manual HERE

Weight1 kg
