Mastech My8301 Multimeter
Features
Display 6000 Counts
Auto range
Auto Power Off
Dual Display
Continuity Buzzer
Data Hold
MAX/MIN
Display Backlight
Low Battery Display
Non-Contact Voltage Detector
Specification
| Specifications | Range | Resolution | Accuracy | |
| DC Voltage | 6V/60V/600V | 0.01V/0.1V/1V | (0.5%+3) | |
| AC Voltage | 6V/60V/600V | 0.01V/0.1V/1V | (0.8%+5) | |
| Resistance | 2kv/20kv/200kv/2Mv | 0.001kv/0.01kv/0.1kv/0.001M?? | (0.8%+3) | |
| 10Mv | 0.01Mv | (1.0%+5) | ||
| Frequency | 60Hz/600Hz/3kHz | 0.1Hz/1Hz/10Hz | (1.0%+5) | |
| Duty Cycle | 10%«?90% | 1% | 2.0% |
Power Supply : 2×1.5V AAA Batteries
Product Size : 150mm x 74mm x 48mm / 5.9”x2.9”x1.7”
Product Weight : 220g / 0.48lb
Certificate : CE / ETL / RoHS
Safety Rating : CAT III 600V
